10W / 20W 6000lm 1200lm Gobo Light Gobo Projector

Model No.: GD23P10C / GD23P20C

Light Type: Track Light

Rated Power: 10W/20W

Voltage: 220-240VAC

Product Name: Gobo Profile Spotlight

Color Temperature: 3000K(warm white) / 4000K(natural white) / 5000K(cold white)

Material: Aluminum Die-cast

Beam Angle: 25°-35° / 25°-45° / 15°-25° / 20°-36°

Lifespan: 50,000 Hours

Working mode: on/off

Certification & Warranty: CE approved, 5 years warranty

Advantages

Versatile Rotation: 355° horizontal and 90° vertical rotation capability for flexible lighting direction adjustment.

Customizable Shapes: Offers multiple spot shapes like round, rectangle, triangle, and more for diverse lighting effects.

Adjustable Beam Angle: Beam angle can be easily adjusted to suit different lighting needs.

Focusing Function: Incorporates a focusing function for precise light control and spotlighting.

Options

ON-OFF
TRIAC
DALI
1-10V

Download

Technical Parameter

Model

Voltage

LED Chip

Power

CCT

CRI

Lumenious Flux of LED

Beam Angle

Installation

Power Supply

GD23P10C

220-240V 50/60Hz

COB

10W

3000K
4000K
5000K

＞80 / 90

600Lm

15°-35°

25°-45°

2 wires

3 wires

4 wires

Integrated Adapter Driver

GD23P20C

220-240V 50/60Hz

COB

20W

3000K
4000K
5000K

＞80 / 90

1200Lm

15°-25°

20°-36°
